Acrylic Resin Reactor

Stainless Steel Reactor Information

The Acrylic Resin Reactor  or stainless steel reactor is a new type of chemical engineering equipment we manufacture on the basis of our constantly introducing advanced technology and applying it into improving our products. The stainless steel reactor (electric, steam, heat-transfer oil heating) consists of autoclave body, cover, jacket, agitator, shaft seals,bearing and driving device. The inner cylinder, cover and other parts contacting with chemical materials are made by acid-resistant 0Cr18Ni9 or 1Cr18Ni9Ti stainless steel plate to ensure durability.
Application: It is widely applied for producing pharmaceuticals, construction materials, chemicals, foodstuffs, pigments and resin products.

Acrylic Resin Reactor Configuration:

1.Volume: 50L~50000L (series of specifications), can be customized as per customer requirement; 2.Components: autoclave body, cover, jacket, agitator, shaft seals,bearing and driving device; 3.Optional Reactor type: Electric heating reactor, Steam heating reactor, Heat conduction oil heating reactor; 4.Optional Agitator type: Anchor type, Frame type, Paddle type, Impeller type, Vortex type, Propeller type, Turbine type, Push-in type or Bracket type; 5.Optional Structure type: Outer coil heating reactor, Inner coil heating reactor, Jacket heating reactor; 6.Optional tank material: SS304, SS316L, Carbon steel; 7.Optional inner surface treatment: mirror polished, anti-corrosion painted; Optional outer surface treatment: mirror polished, machinery polished or matt; 8.Optional Shaft Seal: Packing seal or Mechanical seal; 9.Optional feet form: three pyramidal form or tube type; Find Out More about here

Resin production equipment is a combination of reaction kettles and ancillary equipment selected according to the process requirements. Abster Equipment have accumulated 20 years of resin equipment production experience and have strong production and design capabilities, which can provide users with alkyd resins and polyester resins. Unsaturated polyester resin. Alkyd Resin Reactor, Epoxy resin. Acrylic resin,(PU) amino resin, curing agent, hot melt glue, binder, Silicon oil, light oil and other projects of the engineering design, setting alternative guidance, equipment processing, equipment installation and other key engineering. Relying on the Internet of Things system, real-time monitoring of the operation of each device, ensure safe and efficient production, daily form of reports, factory operations, at a glance, really realize the factory intelligent, digital.

*Principle:
The pan and lid are sealed by flange.

The lower part of the pot has a feeding hole, and there is a blender in the pot. The boiler cover has process tube holes such as feed, stirring, observation, temperature measurement, pressure measurement, Steam extraction fractional, and safe emptying.

The upper part of the lid is fitted with a speed reducer and an electric motor. The drive shaft drives the pot mixer, and the shaft seal device is on the top of the lid.

Heating CLIP sleeve with open into, discharge oil(steam), temperature measurement, air, electric heat rod and other takeover holes. Due to the fact that the user has different production processes and operating conditions, the pot cover process is perforated and the stirring type(pulp type, anchor type, frame type, spiral type, etc.) is used. Support type(suspension or support type) and packing sealing device and other different requirements, can be contacted, separately designed, specially prepared.

  • 1.Volume: 50L~50000L (series of specifications), can be customized as per customer requirement;

  • 2.Components: autoclave body, cover, jacket, agitator, shaft seals,bearing and driving device;

  • 3.Optional Reactor type: Electric heating reactor, Steam heating reactor, Heat conduction oil heating reactor;

  • 4.Optional Agitator type: Anchor type, Frame type, Paddle type, Impeller type, Vortex type, Propeller type, Turbine type, Push-in type or Bracket type;

  • 5.Optional Structure type: Outer coil heating reactor, Inner coil heating reactor, Jacket heating reactor;

  • 6.Optional tank material: SS304, SS316L, Carbon steel;

  • 7.Optional inner surface treatment: mirror polished, anti-corrosion painted; Optional outer surface treatment: mirror polished, machinery polished or matt;

  • 8.Optional Shaft Seal: Packing seal or Mechanical seal;

  • Your Content Goes Here
Get best Quote

Technical Specifications Acrylic Resin Reactor

Reactor Vertical condenser Horizontal condenser Separator
Specification (L) Distill column size (mm) Packing area (m³) Cooling area (㎡) Size (mm) Cooling area (㎡) Size (L) Volume (L)
300 Φ159*560 0.01 0.22 Φ219*1000 2.4 Φ410*450 60
500 Φ159*750 0.015 0.29 Φ219*1500 3.6 Φ410*450 60
1000 Φ194*800 0.025 0.62 Φ273*1500 5 Φ410*450 60
1500 Φ194*850 0.025 0.62 Φ267*2000 6.5 Φ410*450 60
2000 Φ219*1000 0.035 1.0 Φ325*2000 8 Φ600*600 150
3000 Φ273*1100 0.058 1.2 Φ325*2000 10 Φ600*600 150
5000 Φ273*1200 0.065 1.5 Φ377*2000 15 Φ700*750 300
8000 Φ325*1500 0.065 4 Φ426*2000 20 Φ700*750 300
10000 Φ325*1800 0.07 5 Φ426*3000 30 Φ700*750 300
15000 Φ377*1800 0.08 6 Φ450*3000 40 Φ800*750 500
20000 Φ377*1800 0.08 6 Φ450*3000 50 Φ800*750 500
25000 Φ377*2000 0.12 10 Φ455*3000 60 Φ800*750 500
30000 Φ377*2500 0.12 10 Φ475*3000 80 Φ800*750 500
